Since 1987 we have shipped thousands of STRONG mixers, many with optional equipment, to producers of concrete products around the world. It combines the advantages of simplicity, ruggedness and exceptional service life. That translates into excellent value. Continuous development and enhancement has made it a fully mature machine, ideally suited for a wide range of mixing tasks.
|
Model |
SC 20 |
SC 30 |
SC 45 |
SC 60 |
SC 75 |
SC 90 |
SC 120 |
|
Output capacity |
20 M3 / Hr. |
30 M3/ Hr. |
45 M3/ Hr. |
60 M3/ Hr. |
75 M3/ Hr. |
90 M3/ Hr. |
120 M3/ Hr |
|
Mixer unit |
Turbo pan mixer/ twin shaft mixer |
||||||
|
Main mixer reduction gear box |
Imported planetary reduction gear |
||||||
|
Main drive/ electrical motor |
20 HP |
30 HP |
40 Hp |
60 HP |
60 HP |
50 HPx2 nos |
75 HPx2 nos |
|
Material storage unit |
2x2 cross bin |
In line four bin feeder |
|||||
|
Material storage capacity |
20 M3 |
30 M3 |
40 M3 |
60 M3 |
60 M3 |
90 M3 |
100 M3 |
|
Material weighing system |
Digital load cell based weighing of material |
||||||
|
Batch feeding system |
Through inclined belt conveyor/inclined skip bucket |
||||||
|
Cement feeding system |
Through screw conveyor |
||||||
|
Water weighing system |
Digital load cell based weighing of water in separate tank |
||||||
|
Ad mixture dozing system |
Digital load cell based auto admixture dozing system |
||||||
|
Control panel |
Fully automatic PLC based control panel |
||||||
|
Control cabin |
Provided |
||||||
|
Concrete discharge height from G.I. |
4.0 meter from the ground level |
||||||
|
Total connected power ( HP ) |
52 HP |
74 HP |
87 HP |
120 HP |
145 HP |
200 HP |
275 HP |
|
Suggested DG Set |
62 KVA |
82 KVA |
125 KVA |
160 KVA |
200 KVA |
300 KVA |
400 KVA |
