Compact Concrete Batching Plant

Compact Concrete Batching Plant

Since 1987 we have shipped thousands of STRONG mixers, many with optional equipment, to producers of concrete products around the world. It combines the advantages of simplicity, ruggedness and exceptional service life. That translates into excellent value. Continuous development and enhancement has made it a fully mature machine, ideally suited for a wide range of mixing tasks.



CC 20

CC 25

CC 30

CC 45

CC 60

Output capacity

20 M³/ Hr.

25 M³/Hr.

30 M³/Hr.

45 M³/Hr.

60 M³/Hr.

Plant assembly

Whole assembly on single chassis

Mixer type

Turbo pan type mixer/ twin shaft mixer

Main reduction gear

Imported Planetary gear box

Main mixer drive

20 HP

25 HP

30 HP

40 HP

50 HP

Material storage system

2 x 2 cross bin feeder

Material storage capacity

14 M³

14 M³

20 M³

25 M³

30 M³

Material weighing system

Digital load cell based weighing system

Material feeding system

Through inclined belt conveyor

Cement feeding system

Through inclined screw conveyor

Water weighing system

Digital load cell based weighing of water in separate tank

Admixture dozing system

Digital load cell based auto admixture dozing system

Control panel

Fully automatic PLC based control panel

Control cabin


Concrete discharge height

4.2 meter from ground level

Total connected power

48 HP

53 HP

63 HP

77 HP

98 HP

Suggested DG set

62 KVA

62 KVA

82 KVA

100 KVA

125 KVA


  • Computer SCADA system and software
  • Cement storage silos
  • Fly ash feeding system and storage silos
  • Material feeding conveyor
  • Fabricated skid
