Strong Machines Construction Machinery

Reversible With Feeding System

Reversible With Feeding System

Since 1987 we have shipped thousands of STRONG mixers, many with optional equipment, to producers of concrete products around the world. It combines the advantages of simplicity, ruggedness and exceptional service life. That translates into excellent value. Continuous development and enhancement has made it a fully mature machine, ideally suited for a wide range of mixing tasks.

TECHNICAL SPECIFICATION

Description

SRF 12

SRF 15

SRF 20

Output Capacity
123/Hr.
153/Hr.
203/Hr.
Batch Capacity
400 litre
500 litre
670 litre
Batch Cycle Time
120 Sec.
120 Sec.
120 Sec.
Main Mixer Type
Reversible Drum Type Mixer
Mixing and Discharge Of Concrete
Forward rotation of the drum mixes the material and reverse rotation of the drum discharge the concrete
Main Drive Of Mixer
10 HP
15 HP
20 HP
Material Storage System
Unique three separate bin for storing different aggregates
Material Feeding System
Through inclined belt conveyors
Material Weighing System
Digital load cell based accurate weighing system
Material Storage Capacity
12 M 3
15 M 3
15 M 3
Cement Storage hopper
40 Bag
40 Bag
40 Bag
Cement Feeding System
Through inclined screw conveyor driven by geared motor
Cement Weighing System
Digital load cell based weighing of cement in separate hopper
Water Feeding System
Auto water dozing system
Water tank capacity
200 litre
250 litre
300 litre
Admixture dozing system
Auto admixture dozing system
Control Panel
Fully automatic PLC based control panel with internal cabling
Total connected power
35 HP
38 HP
43 HP
Suggest D.G. Set
42 KVA
50 KVA
62 KVA
Concrete Discharge Height
1.2 meter
1.5 meter
1.7 meter

OPTIONAL ACCESSORIES

  • Load out belt conveyor
  • Prefab cabin for control panel
